SenSmart 7100 EC

7100SS-90-A-1022/500P/L1
The battery -powered SenSmart 7100 wireless gas detector, with ultra-low power design and easy to use features, provides the most advanced, economical and reliable true wireless toxic gas detection solution. The SenSmart 7100 is compatible with all RC System’s toxic sensors, including hydrogen sulfide, carbon dioxide, oxygen, hydrogen cyanide and many others.
















FEATURES HIGHLIGHT

  • CSA Certified for Class 1, Division 2 hazardous locations
  • D-cell lithium battery powered for up to 9 months Toxic/Oxygen and 6 months LEL operation
  • Available for both 900Mhz and 2.4Ghz
  • Frequency-Hopping Spread Spectrum (FHSS) technology
  • Typical > 1 mile range with local dipole antenna (900Mhz)
  • Detected gas data transmits on six second intervals
  • Graphic display shows values, units, trend graph, alarm levels
  • Power ON / Power OFF using magnetic wand only
  • Non-intrusive, user-prompted calibration procedure
  • Transmits all setup information to Wireless Receiver
  • Security settings to lock critical parameters
  • Auto-recognition of Smart Sensors uploads calibration data and more
  • Fault supervision circuitry detects failed sensor and transmits warning
  • Setup in hazardous area requires only simple magnetic wand
  • Magnetic mount option available
  • Three adjustable independent alarm levels per sensor
  • ​5 LEDs indicate alarms and communication status
Total Price: $0.00 (0/ea)
Quantity:
Specifications
  • Area Classification: Division 1 Explosion Proof
  • Enclosure Type: Stainless Steel
  • External/Battery Powered Model: Battery Powered
  • 2.4GHz or 900MHz Radio Frequency: 900MHz Radio (License Free in North America)
  • Antenna: 1000-2193 Division 1 2dBi Dipole
  • Gas Type: Hydrogen Sulfide
  • Sensor Range: 0-500ppm
  • Sensor Location: Local Mount with Splash Guard
