SenSmart 7100 EC
»
SenSmart 7100 EC
SenSmart 7100 EC
7100AL-90-A-1022/100P/L1
SenSmart 7100 EC
The battery -powered SenSmart 7100 wireless gas detector, with ultra-low power design and easy to use features, provides the most advanced, economical and reliable true wireless toxic gas detection solution. The SenSmart 7100 is compatible with all RC System’s toxic sensors, including hydrogen sulfide, carbon dioxide, oxygen, hydrogen cyanide and many others.
FEATURES HIGHLIGHT
CSA Certified for Class 1, Division 2 hazardous locations
D-cell lithium battery powered for up to 9 months Toxic/Oxygen and 6 months LEL operation
Available for both 900Mhz and 2.4Ghz
Frequency-Hopping Spread Spectrum (FHSS) technology
Typical > 1 mile range with local dipole antenna (900Mhz)
Detected gas data transmits on six second intervals
Graphic display shows values, units, trend graph, alarm levels
Power ON / Power OFF using magnetic wand only
Non-intrusive, user-prompted calibration procedure
Transmits all setup information to Wireless Receiver
Security settings to lock critical parameters
Auto-recognition of Smart Sensors uploads calibration data and more
Fault supervision circuitry detects failed sensor and transmits warning
Setup in hazardous area requires only simple magnetic wand
Magnetic mount option available
Three adjustable independent alarm levels per sensor
5 LEDs indicate alarms and communication status
Quantity:
Add to Quote
7100AL-90-A-1022/100P/L1 Specifications
Area Classification:
Division 1 Explosion Proof
Enclosure Type:
Aluminum
External/Battery Powered Model:
Battery Powered
2.4GHz or 900MHz Radio Frequency:
900MHz Radio (License Free in North America)
Antenna:
1000-2193 Division 1 2dBi Dipole
Gas Type:
Hydrogen Sulfide
Sensor Range:
0-100ppm
Sensor Location:
Local Mount with Splash Guard
