SenSmart 1400M Millennium IR CO2

1400M-0500/5V/12
The microprocessor based intelligent SenSmart 1400M infrared carbon dioxide gas detector is ideally suited for use in harsh environments and where conventional catalytic detectors are prohibitive. These infrared carbon dioxide gas detectors perform reliably in the presence of silicone and other catalyst poisoning agents and operate in oxygen free environments or where high background gas levels are present.
The SenSmart 1400M can directly connect to SenSmart 3000 , SenSmart 6000 and SenSmart 7000 transmitters to have local display and other advanced functions from those transmitters. Please refer to SenSmart Millennium Sensor Brochure for more details.
FEATURES HIGHLIGHT
  • Virtually maintenance free infrared sensing technology
  • Low cost of ownership with over five years operating life
  • Rugged stainless steel construction with fast response time
  • Requires no routine calibration to ensure proper operation
  • Fault indications for all failure states
  • Patented self-compensating optics with no moving parts
  • Heated optical chamber prevents condensation
  • A multi-layered filtering system protects optics from dirt and water ingress
  • Straight optical path eliminates the need for reflective surfaces, such as mirrors or beam splitters
  • Performs well in the presence of high concentrations or constant background levels of hydrocarbons and in oxygen depleted atmospheres
  • Highly resistant to poisoning and etching
  • Standard 4-20 mA output (source)
Total Price: $0.00 (0/ea)
Quantity:
Specifications
  • Sensor Range: 0-5% VOL
  • Sample Draw Barrel Option: Add Sample Draw Barrel Option
