ST-72 64-Channel Alarm Controller

ST72-5-0466-10-000000-70-5-3233333422
ST-72 64-Channel Alarm Controller

ST-72 64-Channel Alarm Controller

The ST-72 controller provides simultaneous display and alarm functions for up to 64 input variables. 16-32-48-64 channel display modes, and I/O modules arranged in groups of 16 channels, allow economical configuration of systems. This easy-to-configure, user friendly controller is ideal for centralizing display and alarm functions in critical multipoint monitoring applications.

Quantity:


ST72-5-0466-10-000000-70-5-3233333422 Specifications

  • Enclosure: Compact 316 Stainless Steel (NEMA 4X)
  • Wireless Modbus Comm Port 1 Antenna: 1000-2309 Radome 12dBi Yagi
  • Wireless Modbus Comm Port 2 Antenna: 1000-2309 Radome 12dBi Yagi
  • Power Supply: Add 10-0172 115 / 220 VAC 24VDC @ 150 Watts
  • Expansion Option 1: 10-0348 AO for 16 4-20mA Outputs
  • Expansion Option 2: 10-0347 + 8, 10-0192 AI for 16 Bridge Inputs
  • Expansion Option 3: 10-0348 AO for 16 4-20mA Outputs
  • Expansion Option 4: 10-0348 AO for 16 4-20mA Outputs
  • Expansion Option 5: 10-0348 AO for 16 4-20mA Outputs
